●One-man setup
●Winch adaptable to Bexus tripod TR9002 / TR9003
●Quick mount bracket with Bexus tripod TR9002 / TR9003
●Attaches to tripod with 2 locking safety pins
●Winch may be installed on any leg of the tripod
●Anti-release safety system
●Auto locking friction lining
SPECIFICATION
| PRODUCT CODE | PULLING CAPACITY | REDUCTION RATIO | HUB DIAMETER | HANDLE LENGTH | UNIT WEIGHT | CABLE DIAMETER | CABLE STORAGE CAP. |
|---|---|---|---|---|---|---|---|
| FR2003 | 800 lbs. (363.2 kg) | 4.1 : 1 | 1.96 inch (50 mm) | 8.2 inch (210 mm) | 7.7 lbs. (3.5 kg) | 3/16 inch (5 mm) | 70 ft. (21.3 m) |
| FR2004 | 800 lbs. (363.2 kg) | 5 : 1 | 2.75 inch (70 mm) | 12.6 inch (320 mm) | 17.6 lbs. (8.0 kg) |
3/16 inch (5 mm) 1/4 inch (6 mm) |
5 mm cable: 100 ft (30 m) 6 mm cable: 80 ft (20 m) |
