MATERIAL SPECIFICATIONS
●Hex Bar: Aluminum Alloy, min. tensile strength: 5,000 lbs (23N).
●Jaws: Aluminum Alloy, min. tensile strength: 5,000 lbs (23N).
●D-ring assembly: Alloy Steel, min. tensile strength: 5,000 lbs (23N).
PERFORMANCE SPECIFICATIONS
●Tensile Strength: Min. 5,000 lbs (23N).
●Max. Capacity: 425 lbs.
●Fits beam flanges from 1/2" to 1" in thickness and from 3-1/2" to 12"(18", 24") in width.
●Ideal for overhead fixed-position anchor points.
●Nylon bushings provide smooth movement.
●No tools are necessary for fast installation.
Beam Flange Specifications
| FB2012 | FB2018 | FB2024 | |
|---|---|---|---|
| Beam flange width ranging | 3.5 ~ 12 inch (88.9 - 304.8 mm) |
3.5 ~ 18 inch (88.9 - 457.2 mm) |
3.5 ~ 24 inch (88.9 - 609.6 mm) |
| Min. Shaft Breaking Load | 5,000 lbs. (23 kN) | 5,000 lbs. (23 kN) | 5,000 lbs. (23 kN) |
| D-ring Breaking Load | 5,000 lbs. (23 kN) | 5,000 lbs. (23 kN) | 5,000 lbs. (23 kN) |
| Weight | 4.81 lbs. (2.18 kg) | 5.64 lbs. (2.56 kg) | 6.31 lbs. (2.86 kg) |
